SEA EAGLE 200 N

X-BAND FULL SOLID STATE

INNOVATIVE AND DIGITAL NAVIGATION RADAR

Download Datasheet

This is box title
MILITARY & DEFENCE

The new SEA EAGLE-200N is an innovative navigation radar of modern design based on Solid State Power Amplifier (SSPA) and digital technology. The radar transmits in X-Band performing high reliability and high operation.

Applications

  • MARITIME NAVIGATION
  • SURVEILLANCE COHERENT RADAR

Features

  • IMPROVED SAFETY AND SECURITY
    Sea Eagle-200N can be considered as a family of radar designed with the strictest quality standards which uses the most advanced digital technologies able to ensure an high level of detection of small naval targets and excellent safety of the ship’s conduct. It is fully compatible with the IMO resolution MSC.192 (79) and the related international standard IEC 62388 ed. 2. The radar system provides performance of Navigation, Surveillance and Control.
  • INCREASED CAPACITY
    The Sea Eagle-200N provides an high level of detection and automatic tracking of targets, with an high resolution and discrimination capacity, using a compact and light antenna. The radar employs a new generation of high performance coherent transmitter-receiver system, based on the frequency modulated pulse compression technique.
  • OPEN ARCHITECTURE
    The radar system has an open architecture that allows supporting different levels of integration when interfaced with the on-board system. It can meet various mission requirements through serial / analog and Ethernet interfaces.
  • VERY HIGH RELIABILITY AND MAINTAINABILITY
    The technological solutions adopted and the high quality of the components used guarantee the Sea Eagle-200N high reliability and long service life, low maintenance and low life cycle cost. The radar has been designed and built to operate reliably 24 hours operation all year around, with full operational performance even in the most adverse marine environmental conditions. An automatic test – BITE device and software facilitate an easy and efficient maintenance.
  • CAPABILITY FOR SELF-DEFENCE
    The system is able to interface with external self-defence systems, or with the Command & Control for the target designation function. The target designation message, containing the position and the kinematic data, can be sent by ship bus or by a point-to-point connection of the RS422 type.
  • INTERFACE WITH ELECTRO-OPTICAL SYSTEMS
    The system is able to interface, as an option, with external systems of vision (Daylight Camera, IR Camera) for the presentation in a special window, on the operator console, of the video coming from such systems.
  • CONTROL CAPABILITIES
    Sea Eagle-200N incorporates an operating system that provides remote control and monitoring of radar operation in the ships Command & Control room via communication link.
  • INTERFACE WITH WAIS SYSTEM
    The system is also able to fully interface the WAIS sensors, for a correct representation of the “maritime picture”, consisting of cooperating targets, civil traffic and possible asymmetric threats. The message of the WAIS apparatus can be received by ship bus or by a point-to-point connection of the RS422 type.
